9GD-2.5 Trailed Single Disc Lawnmower Introduction
The 9GD-2.5 Trailed Single-Blade Lawnmower is built for reliable forage harvesting. Designed to work with 15–35 kW (20–50 HP) wheeled tractors, it handles both natural grasslands and cultivated pastures with ease. It’s not suitable for wetlands, paddy fields, forests, rocky terrain, or areas with dense stubble.
With a smart, compact design and low power requirements, the mower’s cutting unit lifts and lowers smoothly via the tractor’s hydraulic system, keeping operations simple and reducing downtime. One operator can handle the entire mowing task, making it perfect for small to medium-scale farms.
Manufactured to GB/T 10940-2008 “Reciprocating Mowers” standards and certified by the Agricultural Machinery Test and Appraisal, the 9GD-2.5 combines reliability, efficiency, and safety in a single, easy-to-use machine.
Upgrade your farm’s mowing efficiency today with the 9GD-2.5!
We not only offer lawnmower Conditioner but also provide Hay rake and other products. Click below to learn more.
9GD-2.5 Trailed Single Disc Lawnmower
9GD-2.5 Trailed Single Disc Lawnmower specifications
9GD-2.5 Trailed Single Disc Lawnmower specifications
| No. | Item | Unit | Specification |
|---|---|---|---|
| 1 | Model Name | — | 9GD-2.5 Trailed Single-Blade Lawnmower |
| 2 | Hitch Type | — | Trailed |
| 3 | Cutting Mechanism | — | Reciprocating |
| 4 | Cutting Width | m | 2.5 |
| 5 | Power Range | kW | 15–35 |
| 6 | Operating Speed | km/h | 6–10 |
| 7 | Number of Moving Blades | pcs | 34 |
| 8 | Dimensions (L×W×H) | mm | 2000 × 4300 × 950 |
| 9 | PTO Speed | r/min | 540 |
| 10 | Average Cutting Height | mm | 50–70 |
| 11 | Productivity | hm²/h | 2.0–3.0 |
| 12 | Operators Required | person | 1 |
| 13 | Machine Weight | kg | 490 |
Maintenance Guide
9GD-2.5 Trailed Single-Blade Lawnmower
The 9GD-2.5 Trailed Single-Blade Mower is a reciprocating mower designed for efficient cutting of alfalfa, clover, and natural grasses. Proper routine maintenance ensures stable operation, clean cutting, and long service life.
1. Key Maintenance Notes
- PTO speed: 540 rpm
- Recommended tractor power: 15–35 kW
- Cutting height: 50–70 mm (adjustable)
- Blade material: 65Mn manganese steel (HRC 52–55)
- 2. Conditioning Rollers Adjustment
2. Daily Maintenance
- Lubricate the sickle bar, pivot points, and all moving joints.
- Check blades for cracks, wear, or looseness.
- Clean debris from the safety trip mechanism.
- Confirm cutting height setting before operation.
3. Every 50 Operating Hours
- Inspect blade sharpness; sharpen or replace if dull.
- Check bearings for noise or excessive play; lubricate or replace if needed.
- Inspect crank-linkage system and tighten all fasteners.
4. Seasonal / Periodic Maintenance
- Replace worn or damaged blades with original specifications only.
- Inspect frame, PTO driveline, and hitch connections.
- Clean the entire machine and apply anti-rust protection before storage.
- Store in a dry, covered area when not in use.
5. Safety & Operation Tips
- Always disengage PTO and shut down the tractor before maintenance.
- Ensure PTO speed and tractor power match specifications.
- Test the automatic safety trip mechanism regularly.
- Operate with one operator only; keep bystanders clear.
6.Additional Recommendations
- Increase inspection frequency in wet or uneven field conditions.
- Use standardized replacement parts from authorized suppliers.
- Proper maintenance improves cutting quality, reduces fuel use, and extends machine life.
Summary: As follows:▼
| Maintenance Interval | Component / Area | Maintenance Action | Notes |
|---|---|---|---|
| Daily | Sickle Bar & Linkages | Lubricate all moving and pivot points | Use high-quality agricultural grease |
| Daily | Blades | Inspect for cracks, wear, or looseness | 34 moving blades must remain aligned |
| Daily | Safety Trip Mechanism | Remove debris and check free movement | Protects cutter bar from obstacles |
| Every 50 Hours | Blades | Sharpen or replace if dull | Sharp blades improve efficiency and fuel use |
| Every 50 Hours | Bearings | Check for noise or wear, lubricate if needed | Standardized bearings for easy replacement |
| Every 50 Hours | Crank-Linkage System | Inspect alignment and tighten fasteners | Reduces vibration and wear |
| Seasonal / 200–300 Hours | Blades | Replace worn or damaged blades | Use original 65Mn manganese steel blades only |
| Seasonal | PTO Driveline & Hitch | Inspect for wear and secure connections | Operate at 540 rpm PTO speed |
| Before Storage | Entire Machine | Clean, apply anti-corrosion protection | Store in a dry, covered area |
Electric Lawnmower vs. Manual Lawnmower:
What’s the Difference?
| Feature | Electric Lawnmower | Manual Lawnmower |
|---|---|---|
| Power | Electricity / Battery | Human-powered |
| Effort Required | Low | High |
| Cutting Capacity | Medium | Low |
| Maintenance | Moderate | Very low |
| Noise Level | Low | Silent |
| Best Use | Small–medium lawns | Very small lawns |
Are you looking for a reliable lawnmower manufacturer?
Contact us today to get technical details, pricing, and a tailored solution for your operation.
9GD-2.5 Trailed Single Disc Lawnmower FAQs
Q1: Can the 9GD-2.5 be used on uneven terrain?
▾
The 9GD-2.5 is perfect for pastures and cultivated grasslands, but for steep slopes or rocky areas, a wireless remote control lawnmower or automatic remote control lawnmower for slopes is recommended for safety and ease of operation.
Q2: What are the best sheds for lawnmowers to protect equipment during storage?
▾
Sheds for lawnmowers should be dry, well-ventilated, and weather-resistant. Proper storage helps prevent corrosion on blades and moving parts, extends service life, and reduces maintenance needs during the mowing season.
Q3:What type of tractor is needed for the 9GD-2.5 Trailed Single Disc Lawnmower?
▾
The 9GD-2.5 is designed to work with wheeled tractors of 15–35 kW (20–50 HP). This ensures stable performance while maintaining low fuel consumption during forage harvesting.
Q4:How do I maintain the blades on the 9GD-2.5 mower?
▾
Inspect the lawnmower blade before each use. Sharpen or replace damaged blades regularly to ensure clean cuts and prevent excessive wear on the reciprocating mechanism.
Q5:What makes the 9GD-2.5 high-efficiency forage equipment?
▾
With its compact design, low power demand, and robust reciprocating mechanism, the 9GD-2.5 delivers high-efficiency forage harvesting, consistent cutting, and minimal downtime, perfect for small to medium farms.
Q6:Do you sell lawnmower parts?
▾
Yes.
9GD-2.5 Upgraded Trailed Single Disc Lawnmower Customer Feedback
Liam S. – Agricultural Machinery Buyer
“We upgraded from an older trailed lawnmower to the 9GD-2.5 model this season, and the difference in cutting efficiency is immediately noticeable. The machine handles dense forage smoothly, maintains a consistent cutting height, and shows excellent stability during long working hours. It is clearly built for professional agricultural use rather than light-duty applications.”
Robert H. – Dairy Farm Operations Manager
“Compared with electric lawnmowers, the 9GD-2.5 Upgraded Trailed Single Disc Lawnmower delivers far more power and reliability for large pasture operations. It performs well in thick grass and uneven terrain, with minimal maintenance required during peak season. This is a solid choice for farms that need continuous, heavy-duty mowing performance.”
